Built-in Agent Usage
AxonX Agent uses the Claude backend and a development guide loaded by default to troubleshoot tasks and analyze research results through CLI operations. Direct Job tools can be enabled with job_tools; model conclusions must still be grounded in actual tool results.
This page covers built-in Studio sessions. For external hosts such as Codex or Claude Code and prerequisites of each path, see Agent development.
Before you start
- Configure a service token and start an available backend.
- Prepare Claude backend credentials, URL, and model settings on the service machine; see Agent configuration.
- Set the local token in Studio, select a machine, and open the Agent page.
- First confirm that the tasks or research artifacts are in the selected machine's workspace.
Ordinary tasks do not require Agent calls. Agent calls require an additional model environment and an accessible backend. Without model credentials, you can still inspect records directly through the task page and CLI.
Starting an analysis

Enter a question in New chat under Agent. Press Enter to send or Shift+Enter for a newline. The screenshot shows an empty new session in the static Playground, including the research prompt and development setup guidance. No model request has been sent; data and execution are simulated, and no private history is shown.
Provide a specific Task ID, question, and observation scope. Example prompts:
Check the status, tail logs, and upstream relationships of Task <task_id>.
Distinguish submission failure, execution failure, and missing artifacts,
and suggest evidence-based next steps.Compare the protocols, dates, and cost settings of Backtest Tasks <A> and <B>.
Confirm their common window first, then explain why net returns and summary tables may differ.
Do not treat top30_holdings as the actual position ledger.The development guide covers CLI commands including list_entries, preview_file, list_task_statuses, status, read_task_log, get_task_graph, and get_task_context. The Agent obtains actual information before composing its response.
Avoid asking only to “analyze the latest strategy” without a machine or task scope. If multiple results exist, the model may select a different experiment; ask it to list candidate tasks for your confirmation first.
Develop or optimize a plugin
For code development, use the bundled development guide (enabled by default) or provide the AxonX Skill, set the Agent's cwd to an accessible source checkout, and make SDK file/command tools available. The default cwd is the service workspace, which does not automatically include plugin source. Use the available CLI or explicitly configured Job tools for installation and submission; see Agent configuration.
Give the Agent a research objective, baseline or plugin to optimize, data, evaluation windows, metrics, costs, and execution target. Keep source changes, installation in the selected service, and Task submission separate. Verify the service's schemas and upstream artifacts; wait for upstream success before submitting dependent Tasks. Follow the shared development loop; the Skill and research prompt provides an exploration prompt. Retain code changes and Task evidence separately from session history.
Reading streamed messages
Studio displays text, thinking, and tool blocks, updating them from incremental events. Tool inputs and outputs show what the Agent queried; the final text explains how it interprets the evidence.
- A running Task has not completed; inspect its final state and business output.
- Task success does not guarantee that all research conclusions are reliable; continue checking protocols and samples.
- When a tool fails, the model should identify the data gap explicitly; it must not treat unavailable file contents as facts.
- Only the final
resultrepresents the terminal state of this Job turn; a completed connection does not replace the business success field.
Message blocks are UI representations projected from SDK messages. Do not treat thinking content as a research artifact. For reproducible conclusions, retain actual Task IDs, parameters, artifacts, and calculation definitions.
Resuming and managing sessions
The backend generates a UUID for a new session, and subsequent messages use the same session_id. Local service session storage keeps history, titles, and tags. Studio can open history, rename sessions, set tags, fork, or delete them; see the Agent API for specific interfaces.
Forking creates a new session identity to explore different questions from existing context. It does not copy research Task directories or rerun the research chain. Running sessions cannot be deleted.
Sessions are saved in the current service's configured directory. Switching machines switches the environment containing queries and sessions.
Switching conversations or machines aborts the previous browser stream. Studio skips history reconciliation for that obsolete stream so its errors cannot appear in the newly selected conversation. With session_store_flush: batched, a new session is available in the AxonX store only after the SDK flushes its transcript; the session-start event alone does not mean history has been persisted.
CLI and HTTP calls
axonx --stream true agent_chat \
--message 'List workspace tasks, read their actual status first, then summarize.'To continue a session, use the UUID returned by the backend:
axonx --stream true agent_chat \
--session-id '<returned UUID>' \
--message 'Continue checking the tail logs of the task that failed earlier.'Put HTTP request parameters in arguments:
curl -N 'http://127.0.0.1:1024/jobs/agent_chat/events' \
-H "Authorization: Bearer $AXONX_SERVICE_TOKEN" \
-H 'Content-Type: application/json' \
-d '{"arguments":{"message":"Read actual task status first, then explain existing workspace results."}}'Ordinary /jobs/agent_chat calls return a folded JobResponse; /events returns incremental SSE events. Model calls may take time, so set a reasonable client timeout for the connection method.
Stopping turns and cancelling tasks
Stopping in the Agent UI, or calling cancel_agent_turn, interrupts the current SDK session turn:
axonx cancel_agent_turn --session-id '<running UUID>'Use CLI kill for an independent research execution; a turn interrupt does not replace Task process management.
axonx kill --task-id '<research Task ID to cancel>'Session history remains usable after a turn is cancelled. Terminating an execution is recorded as a failed Task when reconciled. These operations are not interchangeable.
Default tools and permission boundaries
Default job_tools is empty; the query list in the default YAML is a commented example. To use CLI operations, make axonx available in the Agent environment and configure the selected service address and token. Service administrators can explicitly configure Jobs to expose them through the in-process bridge.
However, the Claude SDK's own tools, project settings, plugins, and permission_mode also affect execution capabilities. The default configuration uses bypassPermissions, so an empty or query-only Job list does not make the entire Agent read-only. See configuration details for permission design.
Failure checks
| Symptom | What to check |
|---|---|
| Agent Job missing from the catalog | Token, public Job settings, and component startup |
| Model connection fails | Claude environment configuration on the service machine |
| Session does not exist | Whether session_id belongs to the same machine and session store |
| Requests in the same session wait | The session's turn lock may be held |
| Tool cannot find a task | Current machine, Task ID, and workspace scope |
| Session ends but research still runs | Manage the independent Task lifecycle separately |
